Natural Rubber (NR) Technical Guide: From Rubber Tree to Industrial Products
Published: 2025-08-12 | Reading time: 10 minutes
Executive Summary
Natural Rubber (NR), chemically cis-1,4-polyisoprene, is the only major non-synthetic elastomer in commercial use, accounting for approximately 40% of global rubber consumption. Harvested as latex from the Hevea brasiliensis tree, NR possesses a unique combination of properties unavailable in any single synthetic rubber.
The defining characteristic of NR is strain-induced crystallization (SIC) — under dynamic stress and large deformation, polymer chains align and form micro-crystalline domains that act as self-reinforcing structures. This phenomenon makes NR irreplaceable in applications such as rubber tracks, bridge bearings, and marine fenders where dynamic loading conditions prevail.
Molecular Structure & Property Relationships
NR's high cis-1,4 content (>99%) governs its critical properties:
- • Strain crystallization — molecular chain alignment under stress creates reinforcing micro-crystallites
- • Low glass transition temperature (Tg = −70°C) — excellent low-temperature flexibility
- • High elasticity & low hysteresis — rebound resilience 30–65%, relatively low heat build-up
- • Non-polar backbone — resistant to water, alcohols, and polar solvents; swells in non-polar oils
Key Physical Properties
| Property | Typical Range | Test Standard |
|---|---|---|
| Hardness (Shore A) | 25–95 (commonly 40–70) | ASTM D2240 / ISO 7619-1 |
| Tensile Strength | 14–30 MPa (reinforced ≥27.6 MPa) | ASTM D412 / ISO 37 |
| Elongation at Break | 150–850% (commonly 500–600%) | ASTM D412 / ISO 37 |
| Tear Resistance | ≥25 N/mm (high-grade up to 80 N/mm) | ISO 34-1 |
| Abrasion Loss | ≤80 mm³ (ISO 4649) | ISO 4649 |
| Compression Set | 20–40% (70°C × 22h) | ASTM D395 / ISO 815-1 |
| Density | ~0.93 g/cm³ (pure) / 1.0–1.2 g/cm³ (filled) | ISO 1183 |
Properties by Hardness Grade
| Hardness (Shore A) | Tensile (MPa) | Elongation (%) | Typical Application |
|---|---|---|---|
| 50 | 10–14 | ~600 | Soft seals, cushion pads |
| 60 | 17–20 | 500–515 | General industrial rubber parts |
| 70 | 20–25 | 300–400 | Marine fenders, vibration mounts |
| 80 | 25–30 | 200–300 | High-load wear components |
Temperature Limits
| Parameter | Value |
|---|---|
| Minimum service temperature (static) | −50°C to −55°C |
| Minimum temperature for sealing | −40°C |
| Maximum continuous service | 70–85°C |
| Maximum intermittent/peak | 100°C |
| Glass transition temperature (Tg) | −70°C |
Critical limitation: Above 85–100°C, NR degrades rapidly — heat aging causes hardening, elongation loss, and tensile reduction.
Chemical Compatibility
| Media Class | Rating | Notes |
|---|---|---|
| Water, alcohols, polar solvents | ★★★★★ Excellent | Non-polar backbone inert to polar media |
| Dilute acids & bases | ★★★★ Good–Excellent | — |
| Concentrated acids & bases | ★★★ Fair–Good | — |
| Ketones, aldehydes | ★★★ Fair | — |
| Ozone, UV, weathering | ★ Poor | Requires antiozonant protection |
| Mineral oils, fuels, greases | ★ Poor | Severe swelling and dissolution |
| Aromatic & chlorinated hydrocarbons | ★ Poor | — |
Typical Compounding (phr)
- • Cure system: Sulfur (2–3) + accelerator CBS/TBBS (0.5–1) + ZnO (3–5) + stearic acid (1–2)
- • Reinforcement: Carbon black N330/N550/N774 (30–80) or silica
- • Antidegradant system: 6PPD (antiozonant/fatigue) + TMQ (antioxidant) + microcrystalline wax (surface bloom protection)
- • Processing aid: Aromatic/naphthenic oil (5–15)
NR vs. Synthetic Rubbers
| Property | NR | SBR | CR |
|---|---|---|---|
| Tensile Strength | ★★★★★ | ★★★ | ★★★ |
| Tear Resistance | ★★★★★ | ★★★ | ★★★ |
| Dynamic Fatigue Life | ★★★★★ | ★★★ | ★★★ |
| Resilience | ★★★★ | ★★★ | ★★★ |
| Ozone Resistance | ★ | ★ | ★★★★ |
| Oil Resistance | ★ | ★ | ★★★ |
Key Industrial Applications
| Application | Critical NR Property | Typical Products |
|---|---|---|
| Dynamic load-bearing | High elasticity, low hysteresis, SIC | Rubber tracks, bridge bearings, anti-vibration mounts |
| Impact protection | High energy absorption, tear resistance | Marine fenders, dock buffers |
| Abrasion service | High abrasion & tear resistance | Conveyor belt covers, chute liners |
| Tire industry | Low heat build-up, cut resistance | Truck tire treads, OTR tires |
FAQ
Q: Why does NR outperform most synthetic rubbers in dynamic applications?
NR's strain-induced crystallization (SIC) is the key differentiator. Under high dynamic stress, the oriented polymer chains form micro-crystalline domains that act as an "in-situ reinforcement" mechanism. Most synthetic rubbers (except CR) lack this capability and fail earlier under equivalent dynamic loading conditions.
Q: Can synthetic polyisoprene (IR) replace NR?
IR has the same chemical structure as NR but slightly lower cis-1,4 content (~98% vs. NR >99%) and narrower molecular weight distribution. This results in weaker SIC behavior and lower tensile/tear strength. IR can substitute NR in non-critical applications (footwear, general molded goods), but NR remains essential for high-stress dynamic applications such as tires, bridge bearings, and marine fenders.
Inquiry & Technical Support
Nanjing Yuhang Rubber Co., Ltd. has over 30 years of experience in NR compounding and processing, with products covering rubber tracks, marine fenders, anti-vibration mounts, conveyor belts, and industrial rubber sheets. For technical consultation and samples:
